STAR Heavy Duty 220volt DC- Scrap Handling Magnets

Metquip RentalsProductsNewMagnetsSTAR Heavy Duty 220volt DC- Scrap Handling Magnets
STAR Heavy Duty 220volt DC- Scrap Handling Magnets
No Price Available
features:
specifications: <strong>STAR Model MW5-70L/1</strong>Diameter: 700mmWeight: 492kgCold Amps: 15kW: 3.3Lifting Capacity in kg:Steel ball - 2500CI Ingot - 380/200Cuttings - 120/100 <strong>STAR Model MW5-80L/1</strong>Diameter: 800mmWeight: 623kgCold Amps: 18kW: 5.85Lifting Capacity in kg:Steel ball - 3000CI Ingot - 480/250Cuttings - 150/130 <strong>STAR Model MW5-90L/1</strong>Diameter: 900mmWeight: 807kgCold Amps: 26.6kW: 5.85Lifting Capacity in kg:Steel ball - 4500CI Ingot - 600/400Cuttings - 250/200 <strong>STAR Model MW5-110L/1</strong>Diameter: 1100mmWeight: 1350kgCold Amps: 35kW: 7.7Lifting Capacity in kg:Steel ball - 6500CI Ingot - 1000/800Cuttings - 450/400 <strong>STAR Model MW5-130L/1</strong>Diameter: 1100mmWeight: 2060kgCold Amps: 54kW: 11.9Lifting Capacity in kg:Steel ball - 8500CI Ingot - 1400/1100Cuttings - 700/600 <strong>STAR Model MW5-150L/1</strong>Diameter: 1500mmWeight: 790kgCold Amps: 71.2kW: 15.6Lifting Capacity in kg:Steel ball - 11000CI Ingot - 1900/1500Cuttings - 1100/900 <strong>STAR Model MW5-180L/1</strong>Diameter: 1800mmWeight: 4195kgCold Amps: 102.4kW: 22.5Lifting Capacity in kg:Steel ball - 14500CI Ingot - 2750/2100Cuttings - 1600/1350
brochure:
model:
price:
Description

The STAR Scrap Handling Magnets models MW5-70L/1 to MW5-180L/1 are available in 7 different sizes, and are used for scrap handling, recycling and bulk materials.

Specifications:

STAR Model MW5-70L/1

Diameter: 700mm

Weight: 492kg

Cold Amps: 15

kW: 3.3

Lifting Capacity in kg:

Steel ball – 2500

CI Ingot – 380/200

Cuttings – 120/100



STAR Model MW5-80L/1

Diameter: 800mm

Weight: 623kg

Cold Amps: 18

kW: 5.85

Lifting Capacity in kg:

Steel ball – 3000

CI Ingot – 480/250

Cuttings – 150/130



STAR Model MW5-90L/1

Diameter: 900mm

Weight: 807kg

Cold Amps: 26.6

kW: 5.85

Lifting Capacity in kg:

Steel ball – 4500

CI Ingot – 600/400

Cuttings – 250/200



STAR Model MW5-110L/1

Diameter: 1100mm

Weight: 1350kg

Cold Amps: 35

kW: 7.7

Lifting Capacity in kg:

Steel ball – 6500

CI Ingot – 1000/800

Cuttings – 450/400



STAR Model MW5-130L/1

Diameter: 1100mm

Weight: 2060kg

Cold Amps: 54

kW: 11.9

Lifting Capacity in kg:

Steel ball – 8500

CI Ingot – 1400/1100

Cuttings – 700/600



STAR Model MW5-150L/1

Diameter: 1500mm

Weight: 790kg

Cold Amps: 71.2

kW: 15.6

Lifting Capacity in kg:

Steel ball – 11000

CI Ingot – 1900/1500

Cuttings – 1100/900



STAR Model MW5-180L/1

Diameter: 1800mm

Weight: 4195kg

Cold Amps: 102.4

kW: 22.5

Lifting Capacity in kg:

Steel ball – 14500

CI Ingot – 2750/2100

Cuttings – 1600/1350
